| Input Voltage | Nominal input power | Max Output Power | Efficiency | THD | Max Case Temp | Power Factor | Dimming Method | Dimming Range | Start Time |
|---|---|---|---|---|---|---|---|---|---|
| 120–277 Vac | 17 W, 22 W | 28 W | 80 LPW | 20% | 90 °C | > 0.9 | DMX512-A-RDM | 1–100% | ≤ 500 ms |
Features:
- Integrated AC to DC driver electronics
- Zhaga compliant footprint
- Meets UL8750 Safety-Related Electronics Circuits (SREC) requirements
- Approved for use as thermal cutout for fixture per UL1598
- Tunable CCT range: 1800 K to 6500 K
- Individual RGBW control
- Dimming range: 100–1%
- Warm dim ranges:
- 2850–1800 K (Incandescent profile),
- 3050–1800 K (MR16 Halogen profile)
- Color consistency of ≤ 3 step (2 step typical) MacAdam ellipse
- Designed for field replaceability with front heat sink mounting
- On board overtemperature protection (OTP) with thermal foldback
- Circadian Rhythm lighting support with a controller
Programming:
- Dim-Stop
Applications:
- Architectural Lighting
- Commercial lighting
- Downlights
- Indoor lighting
| ERP Part Number | LES (Light Emitting Surface) (mm) |
Typical Peak Lumens (lm) |
Nominal Efficacy (lm/W) (@ 4000 K) |
Lumen packing Density (lm/in3) |
Bluetooth LE (BLE) Capability |
Dimming | Status | Availability |
|---|---|---|---|---|---|---|---|---|
| AWM1-19-20-NB90X | 19 | 2000 | 80 | 1-100% | production | Check > | ||
| AWM1-19-20-NS90X | 19 | 2000 | 80 | 1-100% | production | Check > | ||
| AWM1-12-14-NB90X | 12 | 1400 | 80 | 1-100% | production | Check > | ||
| AWM1-12-14-NS90X | 12 | 1400 | 80 | 1-100% | production | Check > |
