| Input Voltage | Max. Source Lumens | Typ. Input Power | CCT Range | CRI | Dimming Method | Dimming Range |
|---|---|---|---|---|---|---|
| 120–277 Vac | 1500lm 2000lm 2500lm | 14W 19W 24W | 1800 - 6500 K | 90+ | Casambi | 1–100% |
Features:
- Casambi Wireless control
- Integrated AC to DC driver electronics
- Zhaga compliant footprint
- 3 modes of operation: Tunable White, Static White, Warm Dim
- Designed for field replaceability with front heat sink mounting
- Meets UL8750 Safety-Related Electronics Circuits (SREC) requirements
- Approved for use as thermal cutout for fixture per UL1598
- Configurable maximum light output (40%, 60%, 80%, 100%)
- Configurable tunable CCT range
- Warm dim ranges: 3050–1800 K (MR16 Halogen profile) 2700–1800 K (Incandescent profile)
- CA Title 24, IEEE 1789-2015, & Energy Star Compliant
- Compliant Color consistency of < 3 step (2 step typical) MacAdam ellipse
- On board overtemperature protection (OTP) with thermal foldback
- Circadian Rhythm lighting support with a controller
Applications:
- Architectural Lighting
- Commercial lighting
- Downlights
- Indoor lighting
Notes:
There are currently no notes available at this time.
